What we do
The Core Facility Crystal Structure Analysis (CCSA) specialises in structural analysis of single crystals and powders. Our instrument pool encompasses
- 2 electron single crystal diffractometers with a Jungfrau 1M and a QUADRO detector
- 2 X-ray powder diffractometers
- 2 X-ray single crystal diffractometers
- 1 small-angle X-ray scattering instrument
Whether you have a routine case, or you have a complex sample with special requirements, we are here for you.
CC-BY-4.0
CC-BY-4.0
CC-BY-4.0
The image shows the goniometer head with a mounted crystal, the hybrid pixel detector Eiger2 R500 by Dectris AG, and the collimators for the copper and the molybdenum radiation source. The scene is embedded in a greenish light, that stems from one of the control lights of the radiation sourcces.
